MAGUS IV
MAGUS IVBack to menu Introduction Description Technical datas
| Competition | MAGUS 21 | MAGUS 23 | MAGUS 25 | MAGUS 26 | MAGUS 28 |
| Zoom | 0,91 | 0,963 | 1,00 | 1,0236 | 1,06 |
| Area flat. [m2] | 21,24 | 23,76 | 25,63 | 26,83 | 28,80 |
| Area projected [m2] | 19,13 | 21,46 | 23,19 | 24,28 | 26,07 |
| Span flat [m] | 11,57 | 12,24 | 12,71 | 13,01 | 13,47 |
| Aspect ratio flat. | 6,3 | 6,3 | 6,3 | 6,3 | 6,3 |
| Root chord [m] | 2,29 | 2,43 | 2,52 | 2,58 | 2,67 |
| Cells | 75 | 75 | 75 | 75 | 75 |
| Weight [kg] | 5,9 | 6,1 | 6,3 | 6,6 | 6,9 |
| Weight range [kg]* | 70/85 | 82/97 | 92/107 | 100-118 | 115-135 |
| Min. flying speed [km/h] | 23-25 | 23-25 | 23-25 | 23-25 | 23-25 |
| Max. flying speed [km/h] | 39-42 | 39-42 | 39-42 | 39-42 | 39-42 |
| Max. speed [km/h] (accelerator) | 59-61 | 59-61 | 59-61 | 59-61 | 59-61 |
| Gliding ratio | 9 | 9 | 9 | 9 | 9 |
| Min. sink rate [m/s] | 1,05 | 1,05 | 1,05 | 1,05 | 1,05 |
| CIVL (Breitenerprobung) | * pilot equipped | ||||
